[Discontinued] Gen 2 Standard Actuated TRIO Flatmount

• 3D printed from waterproof and UV resistant thermoplastic that will not warp
• 4 pieces are acetone welded together for near seamless and very strong joints
• 3mm acrylic base is adhered using sikaflex 221.
• Brass heat set inserts ensure screws won’t loosen over time
• Waterproof cable gland replaces the commonly failing Starlink connection (* Note, this requires cutting the Starlink cable and crimping 2x RJ45 plugs to use with shielded waterproof connector)
• EPDM O-ring gasket is compressed by 4.5 mm polycarbonate top with M5 SS hardware

*NOTE: due to the hands on assembly in the manufacturing process, there may be slight variations in textures and colors between mounts.

*All parts needed to complete the install are included in the kit, however you will need the following tools for DIY install:

Table saw, oscillating multitool, or dremel to cut apart the dish

RJ45 Passthrough crimp tool (available on amazon for $20)

3mm hex key/bit for tightening M5 stainless steel screws

Please Note: This is a DIY kit for those with basic tools and hands-on experience. If you'd like us to handle the conversion, select "Yes I will ship my Gen 2 Dish for install". We'll reach out to you via email to coordinate sending in your antenna and 75ft or 150ft network cable in. The Wi-Fi router and metal base are not needed for flat mount conversions. Do not include them in the shipment to us when sending in your antenna for modification.

Overall Dimensions: 1.25"H x 13.55"W x 21.85"L

Color options: Black or White

Mounting options: Through-bolt, magnets, VHB adhesive, combination of VHB adhesive and magnets, suction cups, and tilting option for all the above.

⚠ Using Starlink™ in motion may violate your Terms of Service depending on your service location. Consult your Terms of Service to determine if this applies to you.

⚠ All Gen 2 TRIO Flatmount kits require cutting the antenna dish apart to achieve a low profile. Modifying your Starlink™ antenna will void the warranty and is not endorsed or supported by Starlink™/SpaceX.

⚠ Modifying your dish with power tools comes with risk of damaging the circuitry. Do so at your own risk.

⚠ Given the varying conditions of surfaces this can be mounted to, it is ultimately up to the end user to make sure the antenna mount is sufficiently secured. By purchasing and using this product, you agree to waive any claims that you may have against TRIO Flatmount, www.trioflatmount.com, and included entities, from any and all liability for any loss, damage, expense or injury, including death, that may suffer as a result of the use of the product, due to any cause whatsoever.
